12V 10A 25V PV 30W 6V to 12V Output Dimming Streetlight Controller(SPSTC-1030Li)

To refer user manual please scan the QR code which is pasted on the back side of the product. Panel Specifications: Max Input Voltage(OCV) ? 25V, Max Input PV Total (Watts) ? 180W (12V/36Cell Panels) Battery Voltage-12V, Compatible Batteries – Li-Ion: 11.1V(3S) to 14.8V (4S) / LiFePO4: 12.8V (4S). Load Specifications: LED PCB Design or Rated Voltage: 6V to Battery Voltage -1(kindly specify how it?s specified in spec sheet). Max load Supported: Up to 30Watts Protections: Reverse Polarity For all terminals, Short Circuit for battery & load terminals, Overcurrent for load terminals. Size & weight: L7.6 x W5.2 x H2.0CM, 125g Working Mode: Dusk to Dawn, 24 Hours, TOT mode (can set the load on time before morning coming), Five stage night mode and Programmable Using Remote Unit (to be purchased separately, SPSTC-1030Li). Refer all photos & user manual before purchasing product.
