200W 15A 8-60V DC-DC Step Down Buck Converter Module

Description WHAT IS IT A step down (buck) converter.  It converts a higher voltage to a fixed output voltage WHAT IS IT USED FOR Keep an output voltage stable when the input varies, like a battery as it discharges. HOW DO I USE IT Take the lid off, and connect the input wires to the screw terminals.  Put a voltmeter or one of my meters across the output and, power on and adjust the pot to set the output voltage to the voltage you require.  When happy, power off, connect the load to the output terminals, refit the lid and power on. TECHNICAL SPECIFICATIONS Input voltage range 8V-60V Output voltage range 1V-36V Output current 10A max 15A peak Output power 100W uncooled, 200W properly cooled 71mm x 40mm x 31mm Weighs 77g Overcurrent protection above 15A Reverse input protection OBSERVATIONS The metal is plastic coated and this can be peeled off if you want to. There’s a red LED in the case when input power is present 12V out 8.3A (100W) out : 24V in consumes 4.47A (107W) = 93% efficiency – after 10 minutes heatsink temp 68 degC DELIVERY Dispatched Same weekday if ordered before 3pm.  I hold all my stock in Surrey.  Free 2nd Class Royal Mail tracked.  You can level up to 1st Class. SUPPORT My support is second to none.  Check my feedback.  I will gladly help you before or after purchase.  I love power supplies!  I’ll gladly refund you if it’s faulty or you can return it working if it doesn’t perform as you expect.  Be careful with clone UK suppliers – they’re quite often drop-shippers who have no idea what they’re selling – just check their feedback.
